Description
The GIGABYTE X870E AORUS MASTER is a premium ATX motherboard designed for AMD Ryzen 9000, 8000, and 7000 Series processors. Powered by the AMD X870E chipset, it features a 16+2+2 phase digital VRM design, DDR5 memory support up to 8600 MT/s (OC), and advanced PCIe 5.0 connectivity.
It offers four M.2 slots, including three PCIe 5.0 x4 slots, along with Wi-Fi 7, 5 GbE LAN, and dual USB4 Type-C ports. Its advanced thermal design, high-speed networking, and extensive connectivity make it suitable for high-end gaming, professional content creation, and demanding workstation builds.
Key Specifications:
-
Brand: GIGABYTE
-
Model: X870E AORUS MASTER
-
Chipset: AMD X870E
-
CPU Socket: AMD AM5
-
Processor Support: Ryzen 9000 / 8000 / 7000 Series
-
Form Factor: ATX
-
Power Design: 16+2+2 Phase Digital VRM
-
Memory Type: DDR5
-
Memory Slots: 4 DIMM
-
Maximum Memory: 256GB
-
Memory Speed: Up to 8600 MT/s (OC)
-
Primary Expansion Slot: PCIe 5.0 x16
-
M.2 Slots: 4 (3 × PCIe 5.0, 1 × PCIe 4.0)
-
SATA Ports: 4 × SATA 6Gb/s
-
Wireless: Wi-Fi 7
-
LAN: 5GbE
-
USB: 2 × USB4 Type-C
-
Audio: Realtek ALC1220 HD Audio
-
Form Factor Dimensions: 30.5 × 24.4 cm
Warranty: 3-Year Warranty
